Good performance Handheld Laser Welding Machine 1000w 1500w 2000w for metal

Place of Origin WUHAN
Brand Name QUESTT
Certification CE,ISO9001
Minimum Order Quantity 1 SET
Price 6500$-12500$/SET
Packaging Details wooden case
Delivery Time 10-15 working days
Supply Ability 500 suits each year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Application Hot Selling Laser Welding Machine For Metal Stainless Steel Repairing Wavelength 1064nm
Focal Spot Diameter 0.2-3.0mm Welding Depth 0.1-3.5mm
Product Name Laser Welding Machine Keywords High-quality Laser Welding Machine
Power Supply 220v/50Hz Cooling System Water Cooling
High Light

500w Handheld Laser Welding Machine


1000w Handheld Laser Welding Machine


1500w Handheld Laser Welder

Leave a Message
Product Description

Best Price Handheld Laser Welding Machine 500w 1000w 1500w 2000w With Wire Feeder



Good performance Handheld Laser Welding Machine 1000w 1500w 2000w for metal 0Good performance Handheld Laser Welding Machine 1000w 1500w 2000w for metal 1Good performance Handheld Laser Welding Machine 1000w 1500w 2000w for metal 2Good performance Handheld Laser Welding Machine 1000w 1500w 2000w for metal 3



The hand-held fiber laser welding machine changes the traditional welding method, using a high-intensity laser beam as the heat source for welding, and is equipped with a hand-held welding head to replace the previous fixed optical path. It has the advantages of simple operation, beautiful welding seam, fast welding speed and less consumables. Widely used in aviation, aerospace, sporting goods, jewelry, golf head, medical equipment, aluminum denture, instrumentation, electronics, machining, automotive and other industries, especially for gold and silver jewelry fill the hole, point weld lines, mosaic pieces and claw foot unit area.



1. Wide welding range: The handheld welding head is equipped with 5m-10M original optical fiber, which overcomes the limitation of workbench space, and can be welded outdoors and long-distance welding

2. Convenient and flexible to use: It equipped with movable pulleys, which is comfortable to hold, and can adjust the station at any time. It is free and flexible, and is suitable for various working environment scenarios.

3. Multiple welding methods: Welding at any angle can be realized: overlap welding, butt welding, vertical welding, flat fillet welding, internal fillet welding, external fillet welding, etc., and can weld various complex welded work pieces and large work pieces with irregular shapes.

4. Good welding effect: laser welding has a higher energy density and can achieve better welding results. The welding area has little heat influence, is not easy to deform, black, and has traces on the back. The welding depth is large, the melting is sufficient, and it is firm and reliable.

5. Welding seam does not need to be polished: After welding, smooth and no fish scales, beautiful and no scars, and fewer follow-up polishing procedures.

6. Welding without consumables: The handheld laser welding machine can easily complete the welding, reducing the material cost in production and processing.

7. With multiple safety alarms, the light is automatically locked after the workpiece is removed, and the safety is high.




Model QA-LWF1000H QA-LWF1500H QA-LWF2000H
Average output power 1000W 1500W 2000W
Operation Mode CW/Modulate
Max Modulation Frequency 5KHz
Output Power Stability ±3%
Red Laser Yes
Terminal Type QBH
Beam Quality 1.3M2 1.5M2 1.8M2
Polarization Random
Delivery Cable Length 20M
Power Supply 1 PH 220V five wire connect
Control Mode RS232/AD
Power Consumption 4KW 5KW 6KW
Cooling Water Cooled
Operation Temperature 10-40 degree
Max Depth of welding 2mm 3mm 4mm
Machine Weight 180Kg 200Kg 240kg
