3KW Laser hardening and cladding with CNC robot arm for Metal Materials

Place of Origin China
Brand Name Questt
Certification ISO
Model Number QA-LSP3000
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Wooden boxes
Delivery Time 30-60 days
Payment Terms T/T, Western Union, L/C
Supply Ability 500 sets each year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Laser YAG Diode Laser With Fiber Cable Laser Power 3 - 15 KW
Laser Wavelength 900-1070 Nm Application Laser Shock Peening
Cooling Water Automation With Robotic Arm
High Light

Laser Cladding Equipment


Metal Cladding Machine


3KW Laser Shock Peening Machine

Leave a Message
Product Description

Laser Shock Peening Machine System For Surface Strengthening of Metal Materials 3KW
QA-LSP3000 is a high power laser shock peening machine system, which adopta the latest 3KW laserline diode laser, Kuka 6 axis robot and Siemens control system etc.
The laser shock peening control system includes two robots, one of which is a trajectory robot. During the laser shock peening process, the robot actuator realizes a curved trajectory movement of the laser beam relative to the surface of the workpiece, thereby realizing a specified position on the surface of the machined part. Enhanced treatment; the other is a water delivery robot that can form a uniform and stable water-constrained layer with a thickness of about 1 mm to 4 mm (adjustable) on the metal target, confining the plasma between the constraining layer and the metal target. . The trajectory robot used is a six-axis robot arm to realize complex surface machining trajectory operation. The other robot is for the LCP water Nazal.
The equipment is mainly used for laser processing (laser cladding ) on the surface of shafts, gears, discs, special-shaped parts, etc., to increase the hardness or corrosion resistance of the surface. The laser processing organization has metallurgical combination, small deformation, low interface dilution material, fine microstructure of the microstructure, and high surface fatigue life.
Processing capacity:Fast laser cladding, normal laser cladding, laser hardening, inner hole laser cladding
3KW Laser hardening and cladding with CNC robot arm for Metal Materials 0
1. Suitable for surface strengthening of various metal materials
2. The surface roughness has less influence
3. No heat effect on the workpiece
4. The residual compressive stress layer is deeper
5. The residual compressive stress value is higher
6. The microstructure of the material is more compact and stable.
7. Strong controllability
Metallurgy, mold, machinery manufacturing, petrochemical, light industry, energy, transportation, military and other industries.
Typical applications: automotive mold, mining machinery, coal machinery, petrochemical machinery, generator sets, rolling mill machinery and other large mechanical parts.


Output Characteristics
Pulsed Output(-S)Sing-pulsed output; (-D)Double-pulsed output; (-T)Multi-pulsed output

Pulse Energy



Repetition Rate Range1-10Hz
Beam modeTEM00/ VRM

Energy Stability
(after warm up)

≤2%, over 2 hours
Pulse Width≤9ns
Beam Diameter≤12mm≤16mm
Beam Divergence full angle≤0.5mrad
Operating Conditions
Warm-up Time<10min from standby mode
Temperature Range20-25℃
Electrical and Chiller Eequirements
Power Input220AC, 50Hz
Power Grid Configurationsingle phase
Water Flow Rate(at laser head)>6L/min
Heat Load<1500W
Physics Characteristics

Laser Head
Dimensions L×W×H(mm3)


3KW Laser hardening and cladding with CNC robot arm for Metal Materials 1
1 Q: What is the warranty of the laser shock peening machine?
A: The warranty is 2 year, but we offer whole life after-sale service.
2 Q: What is your payment term?
A: T/T, L/C, Westen Union, etc.
3 Q: What is your after-sale service?
A: Engineers can offer oversea services and we can also offer online service, using online chatting tools like Whatsapp to talk with customers directly for all questions .
4 Q: How is the quality of the machine?
A: Germany high technoloy with good quality.
5 Q: How is the operation of the machine?
A: We offer operation manual and videos, show you how to operate the machine.
We can also send engineers to your factory for training. Or you can send worker to gain training in our factory directly.
