Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W

Product Details

Place of Origin: Wuhan, City

Brand Name: QUESTT

Certification: CE

Model Number: QA-LC100S

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Standard Exporting Wooden Box

Delivery Time: 5 days

Payment Terms: T/T, L/C, Western Union, Paypal

Supply Ability: 2998 sets per year

Get Best Price
Highlight:

Laser Rust Removal Equipment 200W

,

Handheld Laser Cleaning Machine 100W

Laser Types:
Mopa Fiber Laser Source
Laser Power:
50-200W
Wavelength:
1064 Nm
Sevices:
Wholelife Aftersale Service
Certificate:
CE
Warranty:
2 Years
Scanning Width:
10-170mm
Cable Length:
5 Meters
Outlook:
Mobile Case
Keywords:
Laser Rust Removal
Laser Types:
Mopa Fiber Laser Source
Laser Power:
50-200W
Wavelength:
1064 Nm
Sevices:
Wholelife Aftersale Service
Certificate:
CE
Warranty:
2 Years
Scanning Width:
10-170mm
Cable Length:
5 Meters
Outlook:
Mobile Case
Keywords:
Laser Rust Removal
Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W

Handheld Clean Laser Rust Removal Equipment 200W 100W Pulse Fiber Laser Cleaning Machine



Description:

QA-LC100S pulse fiber Laser cleaning machine adopt a 100W mopa pulse fiber laser source.

This kind of laser source is ok to work on most materials.

For suitcase type laser cleaner, the laser power range from 20W to 200W, all are air cooling.

The outlook is the same as a travel case, this special design is good for outdoor cleaning job.

For Agent, you can also take it to travel on airplane for demostration in other places.

The laser head has two scanner motor, so the output laser beam shape have different choice, like waves, circles, squares etc.

The laser system was connected with Phone bluetooth or handheld controller, very convenient for parameter settings.

We also add time counter on App, if for renting, you can see the laser working time and charge by hours.







Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W 0

Characteristic:

1. Phone App operation with bluetooth or handheld controller

2. Suitable for the removal of different materials ;

3. Free to wrok outside

4. Pollution-free;

5. Expansibility;

6. No damage to the base material;.

7. Easy to operate,
8. Time counter on APP interface
Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W 1



Specifications:



Model QA-LC200S QA-LC100S
Laser source Fiber Fiber
Laser Power 200W 100W
Fiber cable length 1.5-5 M 1.5-5 M
Laser Wavelength 1064nm 1064nm
Pulse Energy 1.8 mJ 1.5 mJ
Pulse frequency 1-4000KHz 1-2000KHz
Scanning speed 0-7000mm/s 0-7000mm/s
Cooling Air cooling Air cooling
Dimension 800*350*600mm 500*300*650 mm
Weight 58Kg 29Kg
Beam width 10-170mm 10-100mm
Optional Manual/Auto Manual
Temperature 5-40 ℃ 5-40 ℃
Voltage Single Phase AC 220V,50/60HZ Single Phase AC 220V, 50/60HZ



Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W 2

Application scope



All industries, widely used in aerospace, mold, microelectronics, construction, nuclear power plants, automobile manufacturing, medical, military etcall the old and durty items

Handheld Laser Rust Removal Pulse Fiber Laser Cleaning Machine 200W 100W 3



FAQ



1 Q: What is the warranty of the 100W laser rust removal machine?

A: The warranty is 2 years, but we offer whole life after-sale service. Online service is OK.

2 Q: What is your payment term?

A: T/T, L/C, Westen Union, etc. Any payment term you prefer.

3 Q: What is your after-sale service?

A: Engineers can offer oversea services and we can also offer online service, using online chatting tools like Whatsapp to talk with customers directly.

4 Q: How is the quality of the machine?

A: High quality. Price is reasonable.

5 Q: What is the brand of laser source?

A: Raycus,JPT,GZ,Orion,MAX,IPG etc.
