Jewelry laser cutting machine with Excellent Beam Quality 300W High precision
FL1000-1530 Jewelry laser cutting machine is specially used for jewelry cutting.
Because of the small laser spot, high energy density, fast cutting speed, laser cutting can therefore get better cutting quality.
A. Cutting kerf is narrow and parallel on both sides,also perpendicular to surface, dimensional accuracy of cutting pieces can be up to + / - 0.05 mm.
B. Cutting surface is smooth and beautiful, the surface roughness is only a few dozen microns, laser cutting can be used as the final working procedure, parts can be even used directly without mechanical processing.
C. Heat affected zone is very small, material performance is hardly affected near the kerf width , and the workpiece deformation is small.Also,kerf geometry is good , slitting rectangular cross-section shapes appear to be regular.
1. Double ball screw close-loop system and imported open-type CNC system, ensure high accuracy and high working efficiency during high speed cutting.
2. High Efficiency: The rapid cutting speed is two times higher than that of CO2 laser machine.Its use-cost is low.
3. Enclosure design conforms to CE standard for reliable and safe processing. Pallet changer is convenient for material uploading and unloading and further improving working efficiency.
4. Aiming at high speed cutting, strengthened welded machine body after 2 times of aging process, ensuring long-term accuracy and stability of performance.
5. Dual-pressure gas control system of 3 gas sources (high pressure air, nitrogen, oxygen) meets the processing requirement of all kinds of metals. Easy operation and low cost
6. Automatic nesting software (including material management and optimized processing technology) and providing with database of process parameters for easy operation and simple management.
7. Optimized optical lens, specially designed nozzle and sensor technology realize more stable and smooth cutting. Optional collocation of 2000mmX4000mm, 2000mmX6000mm working table.
8. Dual drive, aging treatment, stress relief test to ensure long time fast running without changing shape;
9. Double ball screw close-loop system and imported open-type CNC system, ensure high accuracy and high working efficiency during high speed cutting.
10. Standard collocation of 1KW fiber laser generator and optional 500W-3000W fiber laser generator. Low operating and maintenance costs. Achieve long-term return on investment and revenue maximization.
|Laser source||Fiber laser (IPG)|
|Max working area||3000x1500mm|
|Working table||Single (double exchange tables optional)|
|Z axis movement||100mm|
|Max cutting speed||18m/min|
|Max cutting thickness||1-16mm according to materials|
|Laser Cutting Head||Auto focus Raytools from Swiserland|
|Servo Motor & Driver||YASKAWA From Japan|
|Reducer with Gear||Shimpo from Japan|
|Rack Pinion||Hiwin from Tanwan(World Brand)|
|Linear Guiderail||Hiwin From Tanwan(world Brand)|
|Control System||CyperCut8000 from Bochu China|
|Oil Lubricated||Automatic lubricated|
|Gantry System||Steel gantry|
|Pneumatic Control||SMC from Japan|
|Machine Dimension||4650*2300*1750 mm|
|Power Protection Level||IP54|
|Voltage||Three Phases 380V, 50HZ
Jewelry aser Cutting Machine is applicable to machinery parts, electrics, sheet metal fabrication, electrical cabinet, kitchenware, elevator panel, hardware tools, metal enclosure, advertising sign letters, lighting lamps, metal crafts, decoration, jewelry, medical instruments, automotive parts and other metal cutting fields.
Training to install:
Option A. We will supply the machine with training video and user's manual in English for installing, operation, maintenance and trouble-shooting, and shall give technical guide by e-mail, fax, telephone/MSN/ICQ and so on, when you meet some problems of installation, using or adjusting
Option B. You can come to Questt factory for training. Questt will offer professional guide. Direct and effective face-to-face training. Here we have assembled equipments, all sorts of tools and testing facility. Training Time: 7 working days
Option C. Our engineer will do a onsite instruction training service at your site. We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before dispatch. It is better to arrange a translator for both of our engineer during the training period. Training Time: 7 days
1 Q: What is the warranty ?
A: The warranty is 2 years, but we offer whole life after-sale service.
2 Q: What is your payment term?
A: T/T, L/C, Westen Union, etc.
3 Q: What is your after-sale service?
A: Engineers can offer oversea services and we can also offer online service.
4 Q: How is the operation of the machine?
A: We offer operation manual and videos, show you how to operate the machine.
We can also send engineers to your factory for training
