600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System

  • 600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System
  • 600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System
  • 600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System
Place of Origin China
Brand Name Questt
Certification CE ISO
Model Number QA60-6040
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Exporting Standard Plywood Box
Delivery Time 5 - 9 days
Payment Terms T/T, Western Union, L/C
Supply Ability 5990 sets / year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Laser Power 60W Laser Type CO2
Service Oversea Service Available Working Area 600x400mm
Warranty 1 Year And Wholelife Service Cooling System Water Chiller
High Light

Laser Engraving Equipment

,

CNC Laser Engraving Machine
Leave a Message
Product Description

CO2 laser engraving and cutting machine for Wood MDF Acrylic nonmetal 600x400mm



Introduction



QA80-6040 CO2 laser engraving cutting machine is a small type laser engraving machine working for not big workpiece and products.



Our precision manufactured lasers and laser systems deliver the highest possible laser engraving performance on a wide variety of materials including wood, glass, plastics, textiles and more. Laser engraving is a non-contact process that will not affect the integrity of the material.



CO2 laser cutting engraving machne is used specially for the nonmetal art crafts, gifts and the engraving of bamboo products. The mechanical structure is strong and stable, making the machine to run at high precision. The electrical ability is stable, the engraving speed is high, and the precision is high.



Its speed and accuracy are guaranteed by using gear grinding with high precision,imported guide rail and laser cutting head under strict assembly.



Features

1. User-friendly hermetic top and bottom exhaust suction system ensures safe working conditions.

2. Synchronous belt drive and semi-closed-loop structure, ensures high precision engraving and fast speed. (engraving speed up to 800-1000mm/s)

3. Equipped with 30W RF metal laser. Output beam of high quality, excellent power stability, long life, low use-cost, maintenance-free, and high efficiency.

4. There is no machine starting cost. Operation cost is low.

5. With CE Certificate

6. Available to work with Windows 7 32/64 bits

7. High engraving speed

8. Safe and durable circuit design.



Specification



Model  QA80-1060  QA60-9060   QA60-6040
Laser CO2 glass sealed laser tube or RF metal sealed laser tube optional
Laser power 60W/80W/100W/130W 60W/80W/100W
Work platform size 1000×600mm                 | 900x600mm                            | 600x400mm
Engraving speed 1-1000mm/s
Cutting speed 1-500mm/s
Worktable honey-comb or slatted optional
Precision ≤±0.025mm
Graphic format PLT,BMP,DXF,DST,TIF
Working temperature 0-45 degree C
Motor type Stepper Motor
Water Cooling Water chiller
The Whole Set

1PCS CO2 laser cutting machine

1PCS Water chiller

1PCS Air pump

1PCS Fan blower
Spare parts Laser tube, Focal lens, Reflector lens(3PCS)
Electricity 220V/50hz/1kva 110V60HZ 220V60HZ





Materials



Items Engraving Cutting

Fabric Denim , leather , polyester , cotton , nylon , pongee ,

suede , jeans ,satin , corduroy , chiffon , tulle , fleece

 yes yes
Wood Plywood , bamboo , veneer , mdf , polymeric materials yes yes

Plastic PP , plastic , ABS plastic , PVC , pipe , polyester ,

sheet , insulation layer

 yes yes
Organic Acrylic , rubber , resin , epoxy yes yes
Paper Packaging materials , tin foil , card , cardboard , chipboard yes yes
Composite Double color plate organic board yes yes

Stone Ceramic , tile , marble ,granite , slate , gravestone ,

porcelain , tombstone , ceramic plate

 yes no

Other Nonmetals process materials , coating materials ,

plating materials , spraying materials

 yes

no





Applications

Applicable to precision engraving on acrylic, wood, double color plates, bamboo, marble, paper, leather and other non-metallic materials.



The industries like advertising logo making, crafts& gifts, crystal, relief sculpture, leather

&cloth, embroidery and decoration.



Samples



600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System 0



Configuration

600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System 1

Machine overlook

600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System 2



600 x 400mm Area CO2 Laser Engraving Machine 60W Water Chiller Cooling System 3
