Home > products > Fiber Laser Marking Machine > Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software

Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software

Product Details

Place of Origin: WUHAN

Brand Name: QUESTT

Certification: CE ISO

Model Number: EM SMART

Payment & Shipping Terms

Minimum Order Quantity: 1

Delivery Time: 5-8 Working days

Payment Terms: T/T

Supply Ability: 2000 sets per year

Get Best Price
Highlight:

50W Raycus Laser Marking Machine

,

30W Raycus Laser Marking Machine

,

20W Raycus Laser Engraver

Certification:
CE ISO
Cnc Or Not:
Yes
Cooling Mode:
Air Cooling
Marking Speed:
0-7000mm/s
Warranty:
1 Year
Laser Source:
Raycus
Applicable Material:
Metal Plastic,Aluminum,Cooper,iron,Stainless Steel
Keywords:
Fiber Laser Marking Machine Price
Working Accuracy:
0.01mm
Control Software:
JCZ Software
Laser Wavelength:
1064nm
Certification:
CE ISO
Cnc Or Not:
Yes
Cooling Mode:
Air Cooling
Marking Speed:
0-7000mm/s
Warranty:
1 Year
Laser Source:
Raycus
Applicable Material:
Metal Plastic,Aluminum,Cooper,iron,Stainless Steel
Keywords:
Fiber Laser Marking Machine Price
Working Accuracy:
0.01mm
Control Software:
JCZ Software
Laser Wavelength:
1064nm
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software

High efficiency raycus mini software ezcad wuhan 20w 30w 50w fiber laser marking machine





FEATURES

* Easily Carried - Net weight 10kg
* Compact Design - Dimension 505mm x 260mm x 440mm
* Plug and Run - Uni-body design, installation-free
* Safety - Fiber wire inside integrated, Protection cover optional
* Artwork Appearance - Deep customization with Raycus, JCZ and Sino-Galvo to be small enough in the body
* CE passed
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 0
Machine details

Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 1
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 2
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 3
Advantages
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 4
Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 5
Parameters

Model
EM-Smart
Laser Type
20watt Fiber Laser (Raycus)
Work Area
110mm * 110mm
Laser Wavelength
1064nm
Marking Speed
≤7000mm/s
Repeat Accuracy
±0.01mm
Minimum Character
0.1mm
Frequency Range
30-60kHz
Operation Temperature
15℃ - 35℃
Cooling Method
Air Cooling Integrated with Fiber Laser Source
Power Supply
AC 110v - 240v, 50Hz / 60Hz
Power Consumption
≤120W
PC Connection
USB Wire
Software
EZcad 2 from Beijing JCZ
Software Language
English / Japanese / Korean / Chinese
Power Outlet Type
US, UK, EU, CN, etc.
Machine Color
White / Blue / Dark Green / Dark Gray
Machine Net Weight
10KG
Machine Dimension
260mm(L) * 440mm(W) * 505mm(H)



Samples



Suitable Materials
* Stainless steel
* Steel and hard metals
* Aluminum and anodized aluminum
* Precious metals
* Brass
* Copper
* Titanium and titanium alloys

* Poly amide (PA)
* Polycarbonate (PC)
* Acrylonitrile butadiene styrene copolymer (ABS)



Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 6



Package

Mini 20W 30W 50W Raycus Laser Marking Machine With Ezcad Software 7
