Promotion 200w 500w 1000w Rust Removal Laser Cleaner 20w 50w 100w Portable Pulse Fiber Laser Cleaning Machine 1000w
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Laser Rust Removal Machine | Laser Source | Fiber Laser Source |
|---|---|---|---|
| Speed | 0-7000mm/s | Laser Wavelength | 1064nm |
| Material | Metal/oxide/painting | Feature | Customizing |
| Certification | CE, ISO | Warranty | 2 Years |
| Service | Online And Overseas Service | Place Of Origin | Wuhan, China |
You can tick the products you need and communicate with us in the message board.
| COLOR | |
|---|---|
| white | |
| black | |
| blue |
Product Description
Product Description:
100W 200W 300W 500W 1000W Rust Removal Laser Cleaner
There is oxidation and corrosion when metals meet oxygen and water vapor in air. It will greatly damage the metal work-piece and the rust will spread from outside to inside and become worse and worse as time goes on, until the whole work-piece is totally corrupted. So rust removal is extremely important. Laser rust removal uses not chemical agents or mechanical polishing, so it is faster and safer.
Laser rust removal Machine is a new generation of industrial surface cleaning laser system. It adopts the advanced laser source, laser optical scanners and control system to meet the requirements of metal surface cleaning process.
Advantages:
1. Versatility: Rust removal laser cleaners come in varying power capacities ranging from 200W to 1000W. This versatility means that they can be used to remove rust from a wide range of surfaces and in different industries, from automotive to industrial manufacturing.
2. Precision: Laser cleaning is a highly precise process that can target rust and other surface contaminants without damaging the substrate. This precision is essential for industries that rely on high-quality finishes.
3. Efficiency: Laser cleaning is an incredibly fast process and can clean large areas in a short amount of time. This efficiency can help businesses increase their productivity and reduce downtime.
4. Safety: Unlike traditional cleaning methods that use abrasives and chemicals, laser cleaning is a non-contact and non-abrasive process that doesn't pose any health risks to operators. This makes it a safer and more environmentally friendly cleaning solution.
5. Cost-effective: Although laser cleaning equipment can be expensive initially, it is generally more cost-effective in the long run than other cleaning methods. This is because it doesn't require consumables like abrasives, and its efficiency helps businesses save on labor costs.
6. Improved quality: Laser cleaning removes rust and other contaminants without damaging the substrate, leaving a clean and smooth surface. This can improve the quality of the finished product and increase customer satisfaction.
Technical Parameters:
| Model | QA-LC100 | QA-LC300 | QA-LC500 | QA-LC1000 |
| Laser source | Fiber | Fiber | Fiber | Fiber |
| Laser Power | 100W | 300W | 500W | 1000W |
| Fiber cable L | 2-8 M | 2-8 M | 10-100M | 10-100M |
| Output fiber L | 5M | 5M | 10M | 15M |
| Pulse Energy | 1.5-10 mJ | 12.5mJ | 25 mJ | 50 mJ |
| Pulse width | 90-130ns | 120-140ns | 90-160ns | 90-160ns |
| Wavelength | 1060nm | 1060nm | 1060nm | 1060nm |
| Frequency | 10-50KHz | 10-50KHz | 10-50KHz | 10-50KHz |
| Clean speed | ≤20 M²/Hour | ≤30 M²/Hour | ≤60 M²/Hour | ≤100M²/Hour |
| Cooling | Water cooling | Water cooling | Water cooling | Water cooling |
| Dimension | 900*450*950mm | 900*450*950mm | 1120*600*1080mm | 1120*600*1080mm |
| Packing | 1000*650*1130mm | 1000*650*1130mm | 1200*680*1250mm | 1200*680*1250mm |
| Net Weight | 90Kg | 100Kg | 220Kg | 280Kg |
| Gross weight | 130kg | 140kg | 280kg | 340kg |
| Beam width | 10-110mm | 10-110mm | 10-170mm | 10-170mm |
| Optional | Manual/Auto | Manual/Auto | Manual/Auto | Manual/Auto |
| Temperature | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ |
| Humidity | <90% | <90% | <70% | <70% |
| Power | < 2500W | < 3000W | < 6000W | < 8000W |
| Voltage | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ |
Applications:
