Imported Rapid Scanner 3D Crystal Laser Engraving Machine With 532 Nm Wavelength

Place of Origin China
Brand Name Questt
Certification CE ISO
Model Number Angel-2000X
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Standard Exporting Plywood Box
Delivery Time 3 - 26 day
Payment Terms T/T, Western Union, L/C
Supply Ability 3600 sets per year

Contact me for free samples and coupons.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Crystal Service Offer Oversea Services
Wavelength 532nm Photo 2D 3D
Crystal Cube Customized Size 150x200x130mm
High Light

3D Laser Glass Engraving Machine

,

3D Laser Etching Machine

Leave a Message
Product Description

Crystal engraving with 3D laser machine glass subsurface etching inner marking

Introduction


Angel-2000X Crystal engraving with 3D laser machine is a bench top type inner laser engraver, which can make pretty crystal and glass cubes souvenirs. See below photo:





The machine give full consideration to the special needs of users in different application directions, high hardware operating efficiency, the effect of fine engraving, good stability of the equipment, low maintenance, especially for artificial crystal, 3D laser engraving glass, acrylic and other transparent rigid material.



The 3D laser inner engraver use the imported air cooling laser system, so it not only greatly increased the speed of engraving, but also with small light point, carving out digital images of high profile distinctive characteristic, good stability and easy maintain.



It has been widely used three-dimensional, two-dimensional crystal photo sculpture, personalized crystal engraving customized gifts, high fineness bulk crystal products processing, glass decoration and other business areas.



Features

1.



2. Imported laser source device



3. The demand for machine movable core components with shockproof system to prevent equipment transportation, use process due to accidental impact damage caused by the core components of the machine



4. The high-speed scanning galvanometer laser work, speeds of up to 220,000 points / minute, saving time carving



5. High stability, carving delicate: the use of advanced air-cooled semiconductor end-pumped solid-state laser technology



6. The use of sealed integrated design, good beam quality, high stability, carved out delicate point. Stable operation for a long time



7. Support multiple data formats: equipped Carvesoft software can support data dxf, cad, bmp, jpg and other formats, it has good compatibility



8. This machine is suitable for individual production and batch fast process.

9. Could be satisfied with capacity for both storefronts network distribution and elecgtric-business distribution.

10. It adopts incorporated structure, and it is good fluid, suited to use in Supermarket.



Specification



Model

Angel-2000X

Laser /Wavelength

semiconductor diode

532 nm

Diode lifetime 25000 hours
Max working scope 150*200*130mm
Engraving dot pitch 0.07-0.12mm
Engraving spot size 40-80μm
Max engraving speed

2500 dots/s

3800 dots/s

Resolution 800-1200 dpi
Batch processing yes
3 axis screw rod accuracy 0.02mm/300mm
3 axis repositioning accuracy <3μm/300mm
Total Power 800 W
Cooling system Air cooling
Temperature 15℃~30℃
Environment humidity <85%, non-dewfall
Air clean, non-corrosiveness gas
Operation system Windows 2000,Windows XP,win7 32bit
Voltage

100-240VAC,5A

50/60HZ

Laser Frequency 2000 HZ
Material Crystal glass etc
Control system with high speed scanner +X+Y+Z (5 axis)
Software self reseach software for 3D, 2Ddots cloud,and for control machine



Imported Rapid Scanner 3D Crystal Laser Engraving Machine With 532 Nm Wavelength 0

Warranty



One year from the date the machine arrives the destination Except consumable part of the lamp and damage artificially.



The seller is responsible for offer free fittings in the warranty period (the buyer has to send the damaged fitting to seller.)



The artificial damage in the warranty period and damage after warranty period, the seller offers paid service.



Samples we make for customers on Canton Fair


Imported Rapid Scanner 3D Crystal Laser Engraving Machine With 532 Nm Wavelength 1

Machine overview

Imported Rapid Scanner 3D Crystal Laser Engraving Machine With 532 Nm Wavelength 2
